Project |
Product Paraneter |
|
|
Module Parameter |
SMD |
SMD2121 |
|
Pixel Pitch |
3 |
|
|
Module Resolution〔W×H) |
4096 |
|
|
Module Size (mm) |
192（W)×192(H)×16.6(D) |
|
|
Module Weight（kg） |
0.46 |
|
|
Working Voltage |
4.5V/5V |
|
|
Module Power（W) |
≤25 |
|
|
Optics Parameter |
Screen Brightness（nits) |
≥500 |
|
Color Temperature（K) |
6500K (1000K一9500K) |
|
|
Viewing Angle |
140/140 |
|
|
Contrast Ration |
208 |
|
|
Electrcial Parameter |
Power Consumption(Max) |
550 |
|
Power Consumption(Average) |
263 |
|
|
Working Voltage |
AC90~132V/ AC186~264V，frequency47-63 (Hz) |
|
|
Applicable Standards |
GB4913/ENG0950 |
|
|
Processing Performance |
Frameshift Frequency |
60Hz |
|
Scan Mode |
32Scan |
|
|
Gray Level |
6124 |
|
|
Refresh Frequency |
1920 |
|
|
Environmental Parameter |
Life Span(H) |
100,000 |
|
Working Temperature/Humidity |
-20℃ -50℃ / 10%-65%RH |
|
|
Storage Temperature/Humidity |
-10℃ - 30℃ / 10%-60%RH |
|
|
Applicable Standards |
SJT 11141-2017.GB/T 26125-2011、GB/T 26572-2001 |
|
