Project |
Product Parameter |
||
|
|
IC2.5 | OC5 | OC8 |
|
SMD |
SMD2121 |
SMD1921 | SMD2727 |
|
Pixel Pitch |
2.5 |
5 | 8 |
|
Module Resolution |
128X64 |
64X32 | 40X20 |
|
Module Size(mm) |
320X160 |
||
|
Module Weight（kg） |
0.4 |
0.44 | 0.48 |
|
Box Size (mm) |
640x640 | ||
|
Box Weight (Kg) |
9 | ||
|
Box Resolution |
256x256 | 128x128 | 80x80 |
|
Module Working Voltage(V) |
4.5V/5V |
||
|
Module Power（W) |
18 |
30 | 31 |
|
Screen Temperature（nits) |
750 |
5028 | 5100 |
|
Color Temperature（K) |
10480 |
9283 | 9125 |
|
Viewing Angle |
160/160 |
||
|
Contrast Ration |
225 |
1576 | 1598 |
|
Power Consumptioh(Max) |
354 |
578 | 598 |
|
Power Consumption(Average) |
247 |
405 | 419 |
|
Input Voltage |
AC90~132V/ AC186~264V, frequency 47-63 (Hz) |
||
|
Applicable Standards |
GB4913/ENG0950 |
||
|
Frameshift Frequency |
60Hz |
||
|
Scan Mode |
32Scan |
28Scan | 16Scan |
|
Gray Level |
4096 |
8192 | 8192 |
|
Refresh Frequency（Hz） |
1920 |
||
|
IP |
IP65 | ||
|
Life Span (H) |
100,000 |
||
|
Working Temperature/Humidity |
-20℃ -50℃ / 10%-65%RH |
||
|
Storage Temperature/Humidity |
-10℃ - 30℃ / 10%-60%RH |
||
|
Applicable Standards |
SJT 11141-2017.GB/T 26125-2011、GB/T 26572-2001 |
||
