Project |
Product Parameter |
|||
|
|
K2.6 | K2.97 | OK3.91 | OK4.81 |
|
SMD |
SMD1515 |
SMD2121 | SMD2121 | SMD2121 |
|
Pixel Pitch |
2.604 |
2.976 | 3.91 | 4.81 |
|
Module Resolution |
96x96 |
84x84 | 64x64 | 60x60 |
|
Module Size(mm) |
250(W)×250(H) |
250(W)×250(H) | 250(W)×250(H) | 250(W)×250(H) |
|
Module Weight（kg） |
0.5 |
0.46 | 0.46 | 0.46 |
|
Box Size (mm) |
500x500/500x1000 | |||
|
Box Weight (Kg) |
6.69 | 6.69 | 6.69 | 6.69 |
|
Box Resolution(dot/m2) |
192x192 | 168x168 | 128x128 | 120x120 |
|
Module Working Voltage |
4.5V/5V |
|||
|
Module Power（W) |
26 |
22 | 24 | 31 |
|
Screen Brightness（nits) |
722 |
714 | 734 | 677 |
|
Color Temperature（K) |
11345 |
11210 | 11666 | 11311 |
|
Viewing Angle |
160/160 |
|||
|
Contrat Ration |
226 |
224 | 230 | 212 |
|
Power Consumption(Max) |
410 |
358 | 376 | 467 |
|
Power Consumption(Average) |
287 |
250 | 263 | 327 |
|
Input Voltage |
AC90~132V/ AC186~264V，frequency 47-63 (Hz) |
|||
|
Applicable Standards |
GB4913/ENG0950 |
|||
|
Frameshift Frequency |
60Hz |
|||
|
Scan Mode |
32Scan |
28Scan | 16Scan | 15Scan |
|
Gray Level |
4096 |
8192 | 16384 | 8192 |
|
Refresh Frequency（Hz） |
3840 |
3000 | 1920 | 3840 |
|
IP |
IP65 | |||
|
Life Span(H) |
100,000 |
|||
|
Working Temperature/Humidity |
-20℃ -50℃ / 10%-65%RH |
|||
|
Storage Temperature/Humidity |
-10℃ - 30℃ / 10%-60%RH |
|||
|
Applicable Standards |
SJT 11141-2017.GB/T 26125-2011、GB/T 26572-2001 |
|||
